SOLUTIONS FOR
Flour, Grain, Rice, Spices, Other Foods, Cattle Feed, Bird Seed, Feed Ingredients, Fish Feed, Sweet Feed, Other Feed, Limestone, Litter, Ice-Melting Salt, Other Minerals, Alfalfa, Corn Seed, Grass Seed, Sorghum Seed, Soybean Seed, Sunflower Seed, Other Seed and Crops, Fertilizers, Plastic Pellets, Other Chemicals
powders and granular materials (food, feed, seed, minerals, chemicals, etc.). They can also handle several kinds of open-mouth bags, including paper bags, polywoven bags, polyethylene bags, etc.
BAG MATERIALS
Laminated polywoven, paper and polyethylene
FEATURES
allows it to reach up to 20 BPM
Rapid and reliable
Low maintenance
Requires little floor space
Optimum reliability
Quick and easy to install and start up
Reduces the number of injuries among workforce
Compatible with every closing system
Technical Data
| Weighing range | 5 to 50kg (10lb to 110lb) |
| Bag size | L630-830mm x W 350-450mm; L800-1000 x W450-550mm; L 900-1100mm x W 550-650mm (By option) |
| Output | 3 to 16 bags per min (Depending on the product and format.) |
| Ambient temp. | -10°C to + 45°C |
| Electrical | 380V/50Hz, 3phase or customized per specification |
| Power | 3KW |
| Air Pressure & Consumption | 0.7Mpa, 0.6 M3／min |
Open mouth baggers can be used in the following types of industries: aggregate, stone, minerals, agriculture, feed, seed, cement, concrete, chemical, food, ingredients, landscaping products and more. Automatically fill open mouth bags with sand, damp sand, sanded cement mixes, concrete, aggregate, soil, dirt, mulch, flour, corn, soybeans, powder, animal feeds, saw dust, cake mixes, cottonseed hulls, plastic pellets, compost, and more.
Qualipak offers a full line of automatic and semi-automatic bagging systems, each designed to handle a special range of bag types and applications. With production rates ranging up to 30 bags per minute, each machine features automatic change over that requires no tools. With a push of a button, the machine adjusts to accommodate a new bag type and transmits all operating parameters to the bagging scale. Thus, in 90 seconds, you are operating again.
