Applications
It’s suitable to use in packing the high accuracy and easy fragile material , such as : puffy food , crispy rice , Potato Chips , Snacks , candy , pistachio , sugar , apple slices , dumpling , chocolate , pet food , small wares etc .
Features
- Famous Brands electrical parts, stable and functional.
- Three servo motor for reciprocationg pull film system, can reach 180bpm.
- Automatically film recitifying function, smart and convenient.
- High speed packing,save labour, resoures and place.
- Many kinds of languages can be chosen.
Optional Device
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications
- Bag Styles:Pillow Bag
- Bag Width:100 to 250mm (3.9 to 9.8″)
- Bag Length:50 to 400mm (2.0 to 15.7″)
- Product Characteristic:Granules, Powders, Liquids, Pastes
- Dosing System Compatible:Volumetric Cup , Piston Filler, Linear Scale , Multi-Head Scale, Auger Filler
- Running Motion:Intermittent
- Working Efficiency: 180 bags / min
- Control By:PLC with HMI Touch Screen
- Date Coding Can Be:Hot Stamping Coder, Thermal Transfer Coder, Label Applicator
- Options Available:Perforation, Dust Absorb, Seal PE Film, SS Frame, SS & AL Construction, Nitrogen Flushing, Coffee Valve, Air Expeller, Heavy Bag, Heating & Mixing Hopper
- Power & Voltage:5 KW
- Compress Air:7MPa 0.4 M3/min
- Dimensions:1600mm*1170mm*1610mm (63.0*46.1*63.4″)
- Machine Weight:950 KGS
14 head combination scale
| Model | ZT-P14L1.6 | ZT-P14L2.5 |
| Weighing Range | 10~1500g | 10~3000g |
| Weighing Accuracy | ±0.1~1.5g | ±0.1~2g |
| Max.Weighing Speed | 70WPM | 70WPM |
| Hopper Capacity | 1.6L | 2.5L |
| Operation Panel | 7 Inch touch screen | |
| Control system | PLC | |
| Power Supply | AC220V±10% 50HZ/60HZ 1.5KW | |
| Packing Dimension | 1100(L)*1100(W)*1780(H) mm | |
| Net Weight | 288KGS | |
| Packing Weight | 400KGS | |
