Applications
Suit for the quantitative weighing of Popcorn, dry pasta, Macaroni, hamburgers, oats, washing
powder, puffed food, French Fries, rice crust, jelly, candy, pistachio nut, apple flake, dumpling,
rice dumpling, chocolate, hardware and medicine such particle, platy, strip and irregular shape.
Features
1.Equipped with safety protection, comply with firm’s safety management requires;
2.Use intelligent temperature controlling machine to have accurate temperature control; ensure the artistic and neat seal;
3.Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center; maximize
the whole machine’s control precision, reliability and intelligentized level;
4.This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging
(exhausting) and products transporting automatically as well as counting;
5.Touch screen can store the technical parameters of various kinds of products, no need to reset while products changing;
6.Have error indicating system, helping to handle the trouble immediately;
7.Make block bags and hanging bags according to customers’ different requires;
8.Both stainless steel machines and carbon steel machines;
9.Single-belt transportation, placidly and quickly, small friction, little waste;
10.Have stainless steel model and carbon steel model for choose.
Optional Device
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications
| Model | ZVF-420 |
| Bag size | L(60~300)×W(40~200)mm |
| Packing speed | 5~60 bags/min |
| Mad width of film roll | ≤420mm |
| Driving film type | by a pair of belt controlled by servo |
| Air consumption | 0.6MPa |
| Gas consumption | 0.4m³/min |
| Power requirement | 2.2KW, 220V, 50HZ |
| Machine size | L1320×W920×H1392mm |
| Machine weight | 550Kg |
Volumetric measuring cup
Volumetric measuring cup is suitable for tiny granule products such as sugar,salt,seed,rice,sesame,gourmet,coffee beans and seasonings,etc.
| Model | Volumetric measuring cup |
| Max. Capacity(g) | 500~1000ml |
| Weighing accuracy(g) | ±1% |
| Max. weighing speed | 45 weighs per minute |
| Capacity | 80L |
| Packing dimension(mm) | 1050(L)×900(W)×1200(H) |
