Applications
Its suitable to use in packing the high accuracy and easy fragile material , such as : puffy food , crispy rice , Potato Chips , Snacks , candy , pistachio , sugar , apple slices , dumpling , chocolate , pet food , small wares etc .
Features
*Imported PLC computer control system with human-machine interface; touch screen is simple and direct-viewing in operation;
*precise positioning with servo film transporting system; excellent complete machine performance and nice packing;
* minimize the loss with complete automatic warn protection function;
* supported with metric device, the machine will automatically complete all packaging processes from measuring, feeding, filling, bag ma
* The way of bag making: the machine can make pillow-type bag and standing bag according to customers requirements.
Optional Device
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications
| Items | Content |
| Packing speed | 5-80 bag/min |
| Bag size | (L)50-300mm (W)60-200mm |
| Bag making mode | Pillow-type bag, standing bag, punch |
| Range of measuring | 150-1500ml |
| The maximum width of packing film | 420mm |
| Thickness of film | 0.04-0.08mm |
| Air consumption | 200L/min 0.7×105Pa |
| Main power/voltage | 2.5KW/220V 50-60Hz |
| Dimension | 1400×970×1600mm |
| The weight of switchboard | 450kg |
14 Heads Multi-head Combination Weigher for snacks
*Select the best combination immediately from diversified weight combinations through computer with perfect combination of high precision and high speed.
*High precision data-type weighing sensor realizes precise weighing.
*Liquid crystal screen operating system in multiple languages such as Chinese and English, etc.
*IP65 grade water-proof and dust-proof design. It’s clean and sanitary with all stainless steel parts. Full sealed design prevents accumulation of material and facilitates cleaning.
*It can fine the opening and closing speed of hopper door according to the features of items to be weighed, and prevent crushing and blocking of material.
*With powerful digital automatic counting function, it can record the index for each batch of product such as total bag number; pass rate and difference of single bag, etc.
*Optional devices: triply balance ball, suction hopper, printing device, tolerance sorting device.
*Strong compatibility and more compact structure with it directly installed on the upper part of packing machine.
*Fast return for investment by largely saving large quantity of raw material and labor cost.
*Net weight: 500kg; Gross weight: 570kg
*Voltage: 220V; Power: 1500W; Frequency: 50/60HZ; Rated current: 9A.
