Applications
Flour, Grain, Rice, Spices, Other Foods, Cattle Feed, Bird Seed, Feed Ingredients, Fish Feed, Sweet Feed, Other Feed, Limestone, Litter, Ice-Melting Salt, Other Minerals, Alfalfa, Corn Seed, Grass Seed, Sorghum Seed, Soybean Seed, Sunflower Seed, Other Seed and Crops, Fertilizers, Plastic Pellets, Other Chemicals
Features
- Provided with the functions of automatic bag-fetching, automatic filling, automatic bag-conveying and sealing.
- Linked with all kinds of powder materials production equipment to work to achieve unattended production of large-sized packaging operations.
- LCD touch screen control, human-computer interface more favorable.
- Automatic fault diagnosis, safety shutdown protection, quick adjustment and easy maintenance.
Packing materials
- Woven Bags (lined with PP/PE film)
- Kraft paper bags
- Plastic composite film (thickness greater than0.18mm)
Technical Data
| Size of bag making | (700-1100mm)x(480-650mm) (L*W) |
| Measuring range | granule material 25-50kg/bag |
| Measurement accuracy | ±50g |
| Packaging speed | 10-15 packs/min (difference according to the packing materials, bag size etc) |
| Ambient temperature | -10°C~+45°C |
| Power supply | 6.5 Kw, 380V±10%, 50Hz |
| Air Consumption | compressed air 0.5-0.7Mpa |
| External dimensions | 5700 x 2800 x 2100mm (L* W * H) |
| Weight | 3000kg |
FAQ
1)How do you control the machine quality before shipping to us?
High Quality is always our Persuit.
a. ISO9001,CE, BV certificate
b. Professional Engineer Team provide the Technical Support;
c. Main core parts are imported, such as Siemens PLC, Schneider Low voltage elements;
d. 304 Stainless steel and our special parts to extand the machine life;
e. Use the same or similar material to test the machine;
f. Wooden case to protect the machine parts.
2)When the machine can be shipped out after payment?
30-45days after your payment.
3)Does your engineer can provide the installation service?
We can guide you to installation.
If you need the overseas service, that is Available, just provide Engineer transporation, shelter,food.
