Bag types
Standup bag, portable bag, Zipper bag, 4-side sealing bag, 3
side sealing bag, paper bag, M type bag etc, and all kinds of compound bags.
Applications
All kinds of liquid and thick-liquid (sauce), such as fruit juice, seasoning sauce, tomato sauce, peanut butter, jam, chili sauce, hand sanitizer, liquid detergent and so on.
Station process
1.bag feeding 2.date coding 3.bag opening 4.filling 5.filling 6.heat sealing 7.heat sealing 8.forming&output
Performance and features
1.wide applications: various state and nature of liquid & thick liquid;
2.A wide range of pouches: all kinds of pre-made pouches;
3.Easy to operate: PLC controller, HMI system makes easy operation;
4.Easy to adjust: change different pouches within 10 minutes;
5.High automation: unmanned in weighing and packing process, machine alarm automatically when failure;
6.Perfect prevention system: when the bag is not opened or not opened completely, it will be non-filling and non-sealing, so the bags can be reused and the product is not wasted thus save the production cost;
7.The product contact parts are adopted SUS304 stainless steel to ensure sanitation and safety, meet the GMP standard;
8.Imported engineer plastic bearings, no need to oil, no contamination;
9.Vacuum generator: low consumption, high efficiency, cleaness, and long useful life;
10.Waterproof design:direct water-washing the machine surface,easy to clean, prolong the useful life
11.Pre-made bag packing: perfect sealing quality, upgrade the finished product.
Technical parameters
| Equipment model | ZG8-200 |
| Equipment material | 304 stainless steel |
| Pneumatic component | SMC,AirTAC |
| Vacuum component | Vacuum generator (SMC) |
| Drive mode | Frequency conversion motor drive |
| Measuring type | Liquid filler, peristaltic pump, draw-off pimp |
| Operation interface | Touch screen(double language:Chinese and English) |
| Bag materials | Heat sealable film as PA/PE,PET/PE,AL film etc. |
| Bag size | W:70~200mm L:100~300mm (date coding requires≥140mm length) |
| Filling range | 5~1500g |
| Packing speed | 20~45bags/min (depended on the product and filling weight) |
| Package accuracy | Error≤±1% |
| Weight | 1000kg |
| Dimension | 1675*1535*1480(L,W,H) |
| Total power | 2.3kw |
| Driving power source | 380V Three-phase Five-line 50HZ |
| Control power source | DC24V |
| Compress air requirement | ≥0.45m³/min (compress air is provided by user) |
