Usage
Suitable for measuring and packing anomalous lumpish and granule materials, such as candy, popped food, biscuit, coffee,roasted seeds and nuts, granulated sugar, deep-frozen food, milk powder, milk tea, amylum, sauce and so on.
Main performance
1.Use the intelligent temperature controller to ensure the accurate temperature, which can be adjusted on the touch screen.
2.Adopt the servo motor controlling for both film-dragging and horizontal sealing, with smooth operation, solid sealing,neat bag shape.
3.Use special bag former with a very vertical sealing, which can make out 4 sides square with smooth iron. After equipping with the gusseting device, it can stand up with solid angel bag profile.
4.Machine has both functions for collecting the extra side-film after cutting, and no collecting the extra side-film, the former type has very nice & flat sealing for vertical sealing, not easy to see the gap, and the latter can save the wrapping film with graceful view.
5.Adopt the convenient vertical sealing structure with shift and slight adjustment; Change various size bag formers, it can bring out different bag dimensions.
6.Equipped with safety protection, comply with firm’s safety management requires;
7.Use intelligent temperature controlling machine to have accurate temperature control; ensure the artistic and neat seal;
8.Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center; maximize the whole machine’s control precision, reliability and intelligentized level;
9.This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging (exhausting) and products transporting automatically as well as counting;
10.Touch screen can store the technical parameters of various kinds of products, no need to reset while products changing;
11.Have error indicating system, helping to handle the trouble immediately;
12.Make block bags and hanging bags according to customers’ different requires;
13.Both stainless steel machines and carbon steel machines;
14.Single-belt transportation, placidly and quickly, small friction, little waste;
15.Have stainless steel model and carbon steel model for choose.
Technical parameters
| Model | ZVF-350Q |
| Bag Type | Quad seal bag, gusseted bag |
| Operation Mode | Intermittent |
| Speed | Up to 50 bags/min |
| Bag Length | 100-420mm |
| Bag Width | 60-220mm |
| Side width | 50-120mm |
| Reel Film Width | 540mm |
| Film Thickness | 0.04-0.12mm |
| Reel Outer Dia | Ф500mm |
| Reel Inner Dia | Ф75mm |
| Voltage | AC 220V/ 50HZ，1phase or per customer needs |
| Power Consumption | 4KW |
| Compressed Air Requirement | 0.6MPa，0.36 M3 / Min |
| Dimension | 1619x1258x1745mm（L x W x H） |
| Weight | 1100KG |
